2 to 12 fiber Breakout Cable is composed of 2 to 12 buffer tubes, aramid yarn, an aramid ripcord, and a PVC outer jacket. Each buffer tube consists of a 900um tight buffered optical fiber surrounded by aramid yarn with a PVC jacket 2mm in diameter. All component materials meet the EU RoHS and REACH Directive standards. Buffer tubes may be color-coded or sequentially numbered.
| Place of Origin | CHINA |
|---|---|
| Brand Name | OptixFiber |
| Certification | ISO9001,CE,FCC,ROHS |
| Model Number | Breakout Cable |
| Minimum Order Quantity | 10KM |
| Packaging Details | 1000M/Wood Roll，Size of Wood Roll：55*55*60cm, Weight:42KG |
| Delivery Time | 10-15days |
| Payment Terms | T/T, L/C, Western Union |
| Supply Ability | 5000KM/month |
Q1: What are the advantages of your price?
A1: We have our own factory, professioanl machinery equipment . We can meet the price advantage of products with the same quality parameters, and we promise to achieve a price of 1%-10% lower than that of our peers.
Q2: What is your quality advantage?
A2: We strictly according to the ISO9001 quality management system, insisting 'Enough Cores, Enough Meters, High Quality, High Performance'. Providing our customers with higher quality products and services.
Q3. Do you support customized brands?
A3: Yes! The professional OEM services will be welcomed to us. Our factory accepts to make the logo free for bulk orders.
Q4: What are the benefits of working with you?
A4: New customers can enjoy AIXTON’s stock and annual year-end dividends, and support long-term cooperative customers to upgrade to global agents and enjoy more discounted prices.fiber optik kablo
| Place of Origin | CHINA |
|---|---|
| Brand Name | OptixFiber |
| Certification | ISO9001,CE,FCC,ROHS |
| Model Number | Breakout Cable |
| Minimum Order Quantity | 10KM |
| Packaging Details | 1000M/Wood Roll，Size of Wood Roll：55*55*60cm, Weight:42KG |
| Delivery Time | 10-15days |
| Payment Terms | T/T, L/C, Western Union |
| Supply Ability | 5000KM/month |
Q1: What are the advantages of your price?
A1: We have our own factory, professioanl machinery equipment . We can meet the price advantage of products with the same quality parameters, and we promise to achieve a price of 1%-10% lower than that of our peers.
Q2: What is your quality advantage?
A2: We strictly according to the ISO9001 quality management system, insisting 'Enough Cores, Enough Meters, High Quality, High Performance'. Providing our customers with higher quality products and services.
Q3. Do you support customized brands?
A3: Yes! The professional OEM services will be welcomed to us. Our factory accepts to make the logo free for bulk orders.
Q4: What are the benefits of working with you?
A4: New customers can enjoy AIXTON’s stock and annual year-end dividends, and support long-term cooperative customers to upgrade to global agents and enjoy more discounted prices.fiber optik kablo
| Product Name | Breakout Cable | Fiber Type | Sinlge Mode |
|---|---|---|---|
| Number Of Fiber | 96 | Cable Structure | Tight-buffered, Loose Tube |
| Cable Diameter | 10.0±0.5MM | Bending Radius | 10D/20D (mm) |
| Outer Jacket Materail | LSZH | Color | Light Yellow |
| Highlight | GJBFJV Breakout Fiber Optic Cable,LSZH Breakout Fiber Optic Cable,GJBFJV Distribution Wire | ||
GJBFJV Indoor Breakout Fiber Optic Cable 48 96 144 Cores Distribution Wire
Indoor Breakout Fiber Optic Cable GJBFJV 12 24 36 48 96 144 Cores Distribution Cables
2 to 12 fiber Breakout Cable is composed of 2 to 12 buffer tubes, aramid yarn, an aramid ripcord, and a PVC outer jacket. Each buffer tube consists of a 900um tight buffered optical fiber surrounded by aramid yarn with a PVC jacket 2mm in diameter. All component materials meet the EU RoHS and REACH Directive standards. Buffer tubes may be color-coded or sequentially numbered.
Applications
• Rugged multi-fiber cross-connects
• Intrabuilding 'backbone'
• Fiber 'backbone' to communications closet
Features
• Sub-units printed every 6 inches
• Tested to meet or exceed EIA/TIA 568-A / GR-409-CORE
• Compliant to Directive 2002/95/EC (RoHS)
• MSHA approved for mining applications
• Tight buffer and sub-unit jacket are available in a variety of colors
Fiber Parameters
CORE SIZE/ FIBER TYPE |
ISO/ IEC |
MAXIMUM ATTENUATION (DB/KM) | OVERFILL LAUNCH MIN. BANDWIDTH (MHZ•KM) |
EMBc (MHZ•KM) | GIGABIT ETHERNET MIN. LINK DISTANCE (METERS) | 10 GIGABIT ETHERNET MIN. LINK DISTANCE (METERS) | |||||
| 850 NM | 1300 NM | 1550 NM | 850 NM | 1300 NM | 850 NM | 1300 NM | 850 NM | 1300 NM | |||
| 62.5/125 | OM1 | 3.5 | 1.2 | N/A | 200 | 600 | N/A | 300 | 550 | 32 | — |
| 50 /125 | OM2 | 3.5 | 1.5 | N/A | 500 | 500 | N/A | 600 | 600 | 82 | — |
| 50 /125 | OM2 | 3.0 | 1.2 | N/A | 700 | 500 | 950 | 800 | 550 | 150 | — |
| 50 /125 | OM3 | 3.0 | 1.2 | N/A | 1500 | 500 | 2000 | 1000 | 550 | 300 | — |
| 50 /125 | OM4 | 3.0 | 1.2 | N/A | 3500 | 550 | 4700 | 1040 | 550 | 550 | — |
| G.657.A1 Single-mode | OS2 | N/A | 0.5 | 0.5 | N/A | N/A | N/A | N/A | 5000 | N/A | 10,000 |
| SM | OS2 | N/A | 0.5 | 0.5 | N/A | N/A | N/A | N/A | 5,000 | N/A | 10,000 |
Cable Parameters
Items | Parameters | |
Fiber count | 96 | |
Tight-buffered Fiber | Diameter | 850μm±50μm |
Material | LSZH | |
Color | Blue Orange Green Brown Gray White Red Black Yellow Purple Pink Aqua | |
Strength Member | Kevlar | |
Jacket | Diameter | 10.0mm±0.5mm |
Material | LSZH/PVC | |
Color | Light Yellow | |
Fiber colour
Blue | Orange | Green | Brown | Grey | White | Red | Black | Yellow | Purple | Pink | Aqua |
Mechanical and Environmental Characteristics
CABLE TYPE |
FIBER COUNT | NOMINAL DIAMETER |
WEIGHT | TENSION | BENDING RADIUS | ||
| LBS (N) | INCHES (CM) | ||||||
| INCHES (MM) | LBS/1000FT (KG/KM) | INSTALLATION | LONG TERM | INSTALLATION | LONG TERM | ||
| Riser Breakout Cable | 4 | 0.33 (8.5) | 44 (65) | 150 (660) | 45 (198) | 5.1 (12.8) | 3.4 (8.5) |
| 6 | 0.40 (10.1) | 64 (95) | 150 (660) | 45 (198) | 6.0 (15.2) | 4.0 (10.1) | |
| 8 | 0.46 (11.6) | 84 (125) | 150 (660) | 45 (198) | 6.9 (17.4) | 4.6 (11.6) | |
| 12 | 0.58 (14.7) | 138 (205) | 150 (660) | 45 (198) | 8.7 (22.1) | 5.8 (14.7) | |
| 24 | 0.65 (16.6) | 118 (175) | 300 (1320) | 90 (396) | 11.4 (29.0) | 7.6 (19.3) | |
| Plenum Breakout Cable | 4 | 0.36 (9.0) | 57 (85) | 100 (440) | 30 (132) | 5.3 (13.5) | 3.6 (9.0) |
| 6 | 0.42 (10.6) | 79 (118) | 100 (440) | 30 (132) | 6.3 (15.9) | 4.2 (10.6) | |
| 8 | 0.48 (12.2) | 105 (156) | 100 (440) | 30 (132) | 7.2 (18.3) | 4.8 (12.2) | |
| 12 | 0.61 (15.5) | 169 (252) | 100 (440) | 30 (132) | 9.2 (23.2) | 6.1 (15.5) | |
