GJFJV indoor fiber optic cable is made by evenly applying strands of Aramid yarns as the strength member over ф900μm or ф600μm tight buffer fibers and then is completed with PVC (LSZH) jacket. High strength aramid yarn strength member ensures tension-resistance and long term stable transmission for optical fibers.
| Place of Origin | CHINA |
|---|---|
| Brand Name | OptixFiber |
| Certification | ISO9001,CE,FCC,ROHS |
| Model Number | GJFJV-6 |
| Minimum Order Quantity | 10KM |
| Packaging Details | 1000M/Wood Roll，Size of Wood Roll：55*55*60cm, Weight:42KG |
| Delivery Time | 10-15days |
| Payment Terms | T/T, L/C, Western Union |
| Supply Ability | 5000KM/month |
| Place of Origin | CHINA |
|---|---|
| Brand Name | OptixFiber |
| Certification | ISO9001,CE,FCC,ROHS |
| Model Number | GJFJV-6 |
| Minimum Order Quantity | 10KM |
| Packaging Details | 1000M/Wood Roll，Size of Wood Roll：55*55*60cm, Weight:42KG |
| Delivery Time | 10-15days |
| Payment Terms | T/T, L/C, Western Union |
| Supply Ability | 5000KM/month |
| Product Name | GJFJV-MM-6F | Fiber Type | OM3 |
|---|---|---|---|
| Number Of Fiber | 6F(Support 24F/36F/48F/96F) | Cable Structure | Tight-buffered, Loose Tube |
| Cable Diameter | 6.2±0.1MM | Bending Radius | 10D/20D (mm) |
| Outer Jacket Materail | LSZH | Color | Light Green |
| Highlight | OM3 OM4 Fiber Optic Cable,om4 multimode fiber Optic Cable,LSZH OM4 Fiber Optic Cable | ||
6 Core Multimode OM3 OM4 Fiber Optic Cable Indoor Optical Fiber Cabling
6 Core Multimode OM3 MO4 Fiber Optic Cable 50/125 GJFJV Indoor Optical Fiber Cabling 62.5/125
GJFJV indoor fiber optic cable is made by evenly applying strands of Aramid yarns as the strength member over ф900μm or ф600μm tight buffer fibers and then is completed with PVC (LSZH) jacket. High strength aramid yarn strength member ensures tension-resistance and long term stable transmission for optical fibers.
Applications
- Adapted to indoor distribution.
- Suitable for external applications in ducts and aerial applications.
- Long distance and local area network communication.
Features
Fiber Parameters
No. | Items | Unit | Specification | |
OM3 | ||||
1 | Mode Field Diameter | 850nm | um | 50±0.5 |
1300nm | um | 50±0.5 | ||
2 | Cladding Diameter | um | 124.8±0.7 | |
3 | Cladding Non-Circularity | % | ≤0.7 | |
4 | Core-Cladding Concentricity Error | um | ≤0.5 | |
5 | Coating Diameter | um | 245±5 | |
6 | Coating Non-Circularity | % | ≤6.0 | |
7 | Cladding-Coating Concentricity Error | um | ≤12.0 | |
8 | Cable Cutoff Wavelength | nm | λcc≤1260 | |
9 | Attenuation(max.) | 850nm | dB/km | 3.5 |
1300nm | dB/km | 1.5 | ||
Cable Parameters
Items | Parameters | |
Fiber count | 6 | |
Tight-buffered Fiber | Diameter | 850μm±50μm |
Material | LSZH | |
Color | Blue Orange Green Brown Gray White Red Black Yellow Purple Pink Aqua | |
Strength Member | Kevlar | |
Jacket | Diameter | 6.2mm±0.2mm |
Material | LSZH/PVC | |
Color | Light Green | |
Fiber colour
Blue | Orange | Green | Brown | Grey | White | Red | Black | Yellow | Purple | Pink | Aqua |
Mechanical and Environmental Characteristics
Items | Unite | Parameters |
Tension(Long Term) | N | 200 |
Tension (Short Term) | N | 660 |
Crush (Long Term) | N/10cm | 200 |
Crush (Short Term) | N/10cm | 1000 |
Min. Bend Radius (Dynamic) | mm | 20D |
Min. Bend Radius (Static) | mm | 10D |
Operating Temperature | ℃ | -20~+60 |
Storage Temperature | ℃ | -20~+60 |
Q1: What are the advantages of your price?
Q2: What is your quality advantage?
A2: We strictly according to the ISO9001 quality management system, insisting 'Enough Cores, Enough Meters, High Quality, High Performance'. Providing our customers with higher quality products and services.
Q3. Do you support customized brands?
A3: Yes! The professional OEM services will be welcomed to us. Our factory accepts to make the logo free for bulk orders.
Q4: What are the benefits of working with you?
A4: New customers can enjoy our stock and annual year-end dividends, and support long-term cooperative customers to upgrade to global agents and enjoy more discounted prices.cavo in fibra ottica
